MaxiSys Elite Manual VIN Input

No Comments in Autel Tools

MaxiSys Elite Manual VIN Input

For some vehicles that do not support the Auto VIN Scan function, the MaxiSys Elite diagnostic system allows you to enter the vehicle VIN manually for quick vehicle identification by CnAutotool.com.

To perform Manual VIN Input
1.Tap the Diagnostics application button from the MaxiSys Job Menu. The Vehicle Menu displays.

27-1
2.Tap the VIN Scan button on the top toolbar.
3.Select Manual Input.
4.Tap the input box and enter the correct VIN.

27-2

5.Tap Done. The Autel Tool will be identified in a few seconds, and once the matching is
successful, the system will guide you to the Vehicle Diagnostics screen directly.

27-3

6.Tap Cancel to exit Manual Input.

No Comments in Autel Tools

Auto VIN Scan

The Autel MaxiSYS Elite diagnostic system features the latest VIN-based Auto VIN Scan function to identify CAN vehicles in just one touch, which allows the technician to quickly detect vehicles, scan all the diagnosable ECUs on every vehicle and run diagnostics on the selected system.

To perform Auto VIN Scan
1.Tap the Diagnostics application button from the MaxiSys Job Menu. The Vehicle Menu displays.
2. Tap the VIN Scan button on the top toolbar.
3. Select Auto Detect. The tester starts VIN scanning on the vehicle’s ECU. Once the test vehicle is successfully identified, the system will guide you to the Autel Diagnostic Scanner screen directly.

22-1

In some cases when users have selected the vehicle brand instead of performing Auto VIN Scan in the first place, the system still provides an option for vehicle VIN scan.

22-2
Select Automatic Selection and the system will proceed to acquire VIN information automatically or allow users to input the VIN manually.

No Comments in Autel Tools

MaxiSys Elite Functional Description

The MaxiSys Elite Diagnostic Platform is the next generation of smart solution for specialized automotive diagnosis. Featuring the NVIDIA’s Tegra? 4-PLUS-1 quad-core 1.90GHz processor, a 9.7” Retina display with a super sensitive capacitive screen, combined with an optimized array of powerful applications, and the best possible coverage of OE-level diagnostics, the MaxiSys Elite performs every job from comprehensive vehicle diagnostics and analysis, to advanced ECU programming quickly and efficiently.

There are 3 main components to the MaxiSys Elite system:
1.MaxiSys Display Tablet 一 the central processor and monitor for the system
2.Vehicle Communication Interface (VCI) 一 the J2534 ECU Programming Device for accessing vehicle data  with programming capabilities
3.Docking Station 一 provides optimum visibility and convenient charging
This manual describes the construction and operation of the devices and how they work together to deliver diagnostic solutions.

This manual describes the con struction and operation of the devices and how they work together to deliver diagnostic solutions

17-1

1. 9.7‖Retina display with capacitive touch screen
2. Built-in Microphone
3. LED Indicator Light–indicates battery level & charging or system status
4. Front Camera
5. Ambient Light Sensor –detects ambient brightness

The LED Indicator Light displays differently in response to the 4 status below:

A. Charged –indicated by steady green light
B. Charging –indicated by steady yellow light
C. Low Battery –indicated by steady red light
D. Standby –indicated by flashing blue light

17-2

6. USB Port – for Ethernet adapter and/or VC I connection
7. HDMI Port
8. Mini USB OTG Port
9. Head Phone Jack
10. DC Power Supply Input Port
11.Lock/Power Button – turns the device on & off with long press, or locks the screen with short press
12. Collapsible Stand – extends from the back to allow hands-free viewing of the display Autel Scanner at a 30-degree angle
13. Removable Battery

17-3

14. Mini SD Slot – optional module
15. Camera Lens
16. Camera Flash/Torch

No Comments in Uncategorized

Cat ET Service Software Deactivation

Instructions for the Deactivation of Cat ET and CAT SIS service software follow the same format.
The examples that are shown in this presentation represent the Cat ET procedure.
Please follow the same process for SIS DVD.

Deactivation – CAT ET
11-1 11-2 11-3 11-4 11-5

Revoke Licenses – Cat ET & SIS DVD
Computers can be lost, smashed, stolen, etc.
Cat ET or SIS DVD Licenses may be Revoked
Revoked Licenses may be REPLACED
Revoked Licenses may be NOT REPLACED

Revoke and Replace License – Cat ET
If a license is Revoked and Replaced, the Total License count in an Order Increases

-> Order XYZ of 10 TOTAL Licenses Exists
5 Licenses are Unassigned and Available
5 Licenses are Assigned
10 total licenses in Order XYZ

-> If one of the 5 Assigned Licenses from CnAutotool.com is Revoked and Replaced
6 Licenses are Unassigned and Available
4 Licenses are Assigned
1 License is REVOKED
11 total licenses in Order XYZ

Revoke and Not Replace License – Cat ET
If a license is Revoked and Not Replaced, the Licen
se count in an Order is Maintained
-> Order XYZ of 10 TOTAL Licenses Exists
5 Licenses are Unassigned and Available
5 Licenses are Assigned
10 total licenses in Order XYZ
-> If one of the 5 Assigned Licenses from Order XYZ is Revoked and Not Replaced
5 Licenses are Unassigned and Available
4 Licenses are Assigned
1 License is REVOKED
10 total licenses in Order XYZ

Revoke License – Cat ET

12-1 12-2

Revoke License

12-3

Revoke & Replace License Results

12-4

Revoke Without Replacement License Results

12-5

No Comments in Auto Scanner Tools

Cat E lectronic Technician (ET)

7-0

Maintain Productivity and Control Cost
Quickly reduce engine and machine downtime, control costs and schedule repairs more efficiently by diagnosing problems using Cat?Electronic Technician (ET).
Cat ET is easy to use. The software accesses information from the electronic control modules on Cat engines and equipment. Using CAT ET, technicians can view status parameters, logged codes, active codes, perform functional tests, and record and view data logs of equipment operation.

7-1
Optimize Profitability
* View active and logged diagnostic codes to quickly identify faulty sensors.
* Review logged event codes to show engine overspeeds, high temperatures, and more.
* Monitor fuel consumption.
* Perform diagnostic tests to quickly identify the root cause of problems.
* Calibrate key components to ensure maximum operating efficiency.
* Use Data Logger to record real-time data.
* View previously recorded data logs to monitor trends in the health of your equipment to ensure peak performance.

Maximize Efficiency
* Search help options to guide every task.
* Retrieve engine data quickly for fuel used, miles traveled, idle time and hours operated.
* Display status of engine speed, throttle position, timing advance, fuel flow and more.
* Check an Diagnostic Tool electronic control module’s configuration and change user settings.

CAT DEALERS DEFINE WORLD- CLASS PRODUCT SUPPORT
We offer you the right parts and service solutions, when and where you need them.
The Caterpillar Electronic Technician network of highly trained experts can help you maximize your equipment investment.

7-2

No Comments in Uncategorized

How to Solve the Issue “ Please Insert TF Card “ for MCT-500 MCT500 Motor Scanner Tool

Recently , there have some customers met the problem “ Please Insert TF Card ” for MCT-500 MCT500 Motor scanner after used it one period time . Like the picture display :

We analyzed this problem , there have 2 situations met the issue :

  1. The TF card from the main unit didnt insert well

Solutions : Please open the back case , check the TF card whether insert well or not , you can take out the TF card , and insert well again



  1. The TF card was damaged or the software from the TF card damaged

Solutions : Please take out the TF card from the main unit , download the latest software into the card , then insert the card to the device test it , if the issue is the software , it can work after you download the new software ; But if the problem still exist , the problem must be the TF card , then you need change the new TF card for the device



Usually , most of our customers met this problem is because the TF card was loosen , just need insert the card well , then the Motorcycle Diagnostic Tool MCT-500 scanner can work again .

Hope all these details can help you solve the issues .

Any other problem , welcome to contact us any time

Thank you

No Comments in Auto Scanner Tools

Installing Caterpillar Electronic Technician

Purpose
The installation procedure described below is for installing your service tool. The installation program is designed to run under Microsoft Windows 98/NT/2000/ME/XP. The installation requires one Install CD-ROM. This installation process will upgrade your CAT ET and preserve files created such as defined Status Groups or service tool report documents.

Note: The service tool will not run from a server over a network.

Instructions
Perform the following steps to install the service tool from the Install CD-ROM:
Step 1 Close any applications you are running. This includes any connections to mainframe computers or networks. only Windows should be running.

Step 2 Insert Caterpillar Electronic Technician Install CD-ROM into your computer’s CD-ROM drive.

Step 3 Press the “Start” pushbutton on the Task Bar. From the menu, select “Run.” The Run dialog box is displayed.

27-1

Step 4
In the text box type the following:
z:\setup.exe
If the CD is in a CD-ROM drive other than “z,” substitute “z” with the appropriate drive letter.
Step 5 Press “OK.” The “Setup is preparing…” status box is displayed

27-2
This status box shows the percentage status of the InstallShield Wizard setup. When it is finished, the Welcome dialog box is displayed

27-3
Step 6 Read through the welcome message. Press the “Next>” pushbutton to continue the setup. The Software License Agreement dialog box is displayed. Press “Cancel” to abort the setup process.

27-4

Step 7 Read through the license agreement. Press the “I Agree” pushbutton to accept the terms and conditions. The Select Components dialog box is displayed

You must have at least Internet Explorer version 5.5 installed on your PC to run the service tool. If you do not have Internet Explorer on your PC, you must install CAT Electronic Technician. If you have an older version of Internet Explorer on your PC, it may not support the service tool, and you need to update your current version of Internet Explorer. Press “Yes” in the Install Internet Explorer dialog box to begin the installation.

Note:A message box may display asking you to reboot. Rebooting is required before continuing installation.

Upgrade information:
If you are upgrading from a previous version of the service tool, and if your current Automotive Diagnostic Scanner is licensed, the License dialog box is displayed showing the current license number. Write down the license number and keep it in a safe place. Press “OK.” The Select Components to Install dialog box is displayed.

NOTICE: To keep your existing license, always install the service tool in the same folder as the previous installation.

27-5

Step 8
Select the check box corresponding to the components(s) you wish to install.

Browse
To select a path different from the one shown in the Destination Folder area, press the “Browse…” pushbutton. The Choose Folder dialog box will display. In this dialog box, you can change the directory path by selecting the drive and folder that you want to install to by typing the complete path in the Path text box.  Disk Space

To check available hard disk drive space for all available drives, press the “Disk Space…” pushbutton. The Available Disk Space dialog box will display.  Changing the drives in the Available Disk Space dialog box changes the drive your destination folder is pointing to in the Select Components to Install dialog box. Press the “Next>” pushbutton to continue the setup. The Select Languages dialog box is displayed. Press “<Back” to return to the previous screen. Press “Cancel” to abort the setup process.

27-6

Step 9
Select the check box next to the language(s) you wish to install. Press the “Next>” pushbutton to continue the setup. If more than one language is selected, the Select Default Language dialog box is displayed. Press “<Back” to return to the previous screen. Press “Cancel” to abort the setup process.
Select All To select all language check boxes, press the “Select All” pushbutton.
Clear All Pressing the “Clear All” pushbutton clears
all checked languages except English,
which is always checked

27-7

Step 10
Select the radio button corresponding to the default language you want. You can change the language later in the service tool.  Press the “Next>” pushbutton to continue the setup. The Select Program Folder dialog box is displayed. Press “<Back” to return to the previous screen. Press “Cancel” to abort the setup process.

Select the radio button corresponding to the default language you want. You can change the language later in the service tool.Press the “Next>” pushbutton to continue the setup. The Select Program Folder dialog box is displayed. Press “<Back” to return to the previous screen. Press “Cancel” to abort the setup process.

27-8

Step 11 Caterpillar ET is the default Program Folder name. If you want to change the Program Folder name, select a folder from the Existing Folders text box, or type a folder name in the Program Folders text box.

Press the “Next>” pushbutton to begin copying files. The Setup screen is displayed. Press “<Back” to return to the previous screen. Press “Cancel” to abort the setup process.

Note:
A dialog box displays the question, “Would you like this installation to put the service tool icon on your desktop?” Press “Yes” to place the icon on your desktop, or press “No” if you do not want the icon placed on your desktop. Once the service tool icon is placed on your desktop, this dialog will not display.

Step 12 The setup process begins copying files. Press “Cancel” to abort the setup/install procedure.

When the installation process is successfully completed, the Setup Complete dialog box is displayed. The Setup Complete dialog box varies depending upon whether or not the computer must be restarted to complete the installation or if you need to license your service tool.

When installing the Communication Adapter II, a message box is displayed with important instructions about the Communication Adapter II. Press “OK.”

Warning for service tool user:
If you are installing the service tool on Windows 2000 or XP, a warning box displays suggesting that anyone running Caterpillar Electronic Technician be a member of the “Power User”group. Press “OK.”

27-10

Step 13
If the Setup Complete message box displays the following message: “Some files were locked – Must Reboot to Finish Setup” , then you must restart your computer to complete the setup.

27-11

Note: If you do not install the Comm Adapter II software, the WARNING message does not display in this dialog box.
Select the “Yes, I want to restart…radio button to restart your computer now, or select the No…” radio button to restart your computer later. Press The “Finish”pushbutton to complete the setup. The “<Back” pushbutton is disabled.

Note: If you elect not to reboot at this time, the service tool will not operate correctly.

OR–
If upgrading from a licensed version, the Setup Complete dialog box is displayed with the following message: “Setup can launch the Read Me file and Caterpillar Electronic Technician.”

27-12

Select the appropriate check box depending on whether you want to launch Read Me or start the service tool. Press the “Finish” pushbutton to complete the setup. The “<Back” pushbutton is disabled.
OR–
If the service tool is not already licensed, the Setup Complete dialog box is displayed with the message: “Setup can launch the Read Me file and License Caterpillar Electronic Technician” .

27-13

Select the appropriate check box depending on whether you want to launch Read Me or License Caterpillar Electronic Technician. Press the “Finish” pushbutton to complete the setup. The “<Back” pushbutton is disabled.

Note: See “Licensing Caterpillar Electronic Technician,” section 4,

How to install and update VPECKER E4 Tablet Diagnostic Tool

VPECKER E4 Tablet Client software upgrade to 5.0 version:

1, Optimize UI display.

2, Fix some bugs.

3, Improve diagnostic capabilities and communication layer stability.

4, New model software update reminder.

5, Optimization of diagnostic data flow interface interaction.

6, New freeze data stream refresh function.

7, Add history reminder for diagnostic menu click.

Then you are supposed to upgrade VPECKER E4 Tablet, here you can go to install in 3 steps.

Steps:

1, Please click Settings-OS Version in the main interface of VPECKER E4.

2, Please click 2-0 2-1

2-2

Please wait for the upgrade package to download. After complete, the tablet will

automatically start VPECKER E4 installation interface, please follow the guide to

install.

3, Please click “Install”.

2-3

2-4

Note: After installation, please log in IDUTEX Store to re-download all car software.

Read: VPECKER E4 Tablet User Manual

No Comments in Auto Scanner Tools

How to use OBDSTAR X300 DP Program Smart Key for BWM FEMBDC

Most of the latest BMW vehicles adopt FEM/BDC modules, which must be programmed before the key programming. OBDSTAR X300 DP already updated the BMW FEM/BDC key programming software. To make the operation clear, let’s show the FEM smart key programming process with Key Mater DP as below:

Prepare

To get a better understanding of BMW key programming, following three major steps and some tools will be explained first.

1.Key Information

2.Key Programming Preprocessing

3.Key Add/Delete

Before key programming, read key information of current vehicle. Then delete the lost key or add new key based on this information.

For these vehicles to be programmed for the first time with this kind of device, Key Programming Preprocessing is necessary before key adding and deleting. Key programming Preprocessing can be operated in the car or on workbench, while operating with specialized test cable on workbench is strongly recommended. FEM test cable is shown below:1

22 (1)

To read and write data on chip of FEM/BDC, it’s necessary to prepare and EEPROM. EEPROM/PIC picture is shown below:

22 (2)

Stpe1:    Key Information Reading

After connecting vehicle or test harness, select “Key Information” under BMW Immobilizer menu to read current key information:

22 (3) 22 (4) 22 (5) 22 (6)

Notice: It will remind you to operate preprocessing in this step. If the vehicle was programmed for the first time, it’s necessary to operate key programming preprocessing. If not, operate Key Add or Key Delete directly.

22 (7) 22 (8)

This is showing FEM module information. Click ”OK” to continue.

22 (9)

This is showing current key numbers, position, and ID. Based on demand, delete lost key and add new key in the position of Not Occupied/Starting during key programming.

22 (10)

Stpe2:    Key Programming Preprocessing

It’s required to operate key programming preprocessing if the vehicle was programmed with the device for the first time. After reading key information, click “OK” back to main menu and select “Key Programming Preprocessing”:

22 (11)

There are seven steps in processing. Start from the first step:

22 (12)

Step 1: Code data backup

Select and click “Code data backup”

22 (13)

22 (14)

Read the code data and click “yes” to save it with the filename by default. Or click “no” to customize filename and remember it (the filename will be helpful in step7)

22 (15)

Code data backup completed.

22 (16)

Step2: EEPROM Original Data Backup

Select “EEPROM original data backup”

22 (17)

During the step2, the screen will show a simple operation instruction. The operation process differs from the user’s programmer, here we take Key Master DP and EEPROM/PIC adapter for example. Shown as below:

Disassemble the FEM/BDC module from car or test cable, open the shell and weld the 95128/95256 chip and take it out.
22 (18)

Weld the 95128/95256 chip to the 95XXX position on the adapter board or insert to the chip holder with the chip clip, (pay attention to the direction of the chip) as following:

22 (20)
22 (21)

Then, connect the EEPROM adapter with Key Master DP, plug in the 12V power, shows as below:

22 (22)

Exit immobilizer function and go back to the main screen, then choose “EEPROM/PIC adapter”:

22 (23)

22 (24) 22 (25)

22 (26) 22 (27) 22 (28) 22 (29) 22 (30)

22 (31)

22 (32) 22 (33)

Notice: The original EEPROM data backup completed and saved with the name“FEM00000”. Disassemble 95128/95256 chip from adapter board and weld back to FEM/BDC module.

Step3: Service Mode Data Generation

Put FEM/BDC module back to car or connect with the test cable. Exit the “EEPROM/PIC adapter” function, enter Immobilizer and choose BMW vehicles, click “step 3: service mode data generation”:

22 (34) 22 (35) 22 (36)

Service mode data generation succeeded and saved directly on the Key Master DP, as the picture shows above. Click “ok” to go back to the last menu.

22 (37)

Stpe4: Service Mode Data Writing

Click “step 4: service mode data writing”:

22 (38)

22 (39)

This step needs the EEPROM/PIC adapter or other programmer to read and write 95128/95256 chip. If you use other programmer to write service mode data, you need to copy the generated service mode data from Key Master DP and reserve it on the programmer or PC computer, then write the data.

Write service mode data with EEPROM/PIC adapter as follow:

① Disassemble 95128/95256 chip again, weld it to the adapter, connect with the Key Master DP.
22 (40)

② Exit BMW Immobilizer, go back to the main menu, choose the EEPROM/PIC adapter.

22 (41) 22 (42) 22 (43)
22 (42)
22 (45)
22 (46)
22 (47)

22 (48)

Input a filename randomly, a different name from the backup EEPROM data in step 2.

22 (49)

Do not exit after the profile reserved. Click “Help” and choose the service mode data “FEM00000(Calc)”.

22 (50) 22 (51)

Make sure again the written data is right. If you use other programmer, please copy the service mode data “FEM00000(Calc)”from the position shown in the picture.

22 (52)
22 (53)

Service mode data recover completed. Click “ok” to go back to the last menu and exit EEPROM/PIC adapter function.

22 (54)

Step5: FEM or BDC module programming

Weld the 95128/95256 chip back to FEM/BDC module, put the module back to car or connect to the test cable, connect the Key Master DP with car or the OBDII for test cable. Exit EEPROM/PIC adapter function, enter key add pre menu, choose “step 5: program FEM/BDC module”.

22 (55)

After the program completed, click “ok” to go back to the last menu.

22 (57)

Step6: EEPROM Original Data Recovering

The procedures for EEPROM data recovering is the same as the service mode data writing. The only difference is the different writing data. Select the EERPOM original data saved in the step2. Operate according to the service mode writing, the data selected is as following:

After read the saved data, then click “help” and choose the saved EEPROM original data “FEM00000.BIN”.

22 (58)

22 (59)
22 (60)
EEPROM original data recovery completed. Click “ok”, exit EEPROM/PIC adapter function and weld the 95128/95256 chip back to the FEM/BDC module.

22 (61)
Step7: Code Data Recovery

Put FEM/BDC module back to car or connect with test cable, Key Master DP connect car or OBDII for test cable. Enter the menu “key programming preprocessing”, choose “step 7: code data recovery”.

22 (62)

22 (63)

22 (64)

Coding succeeded. Key add pre operation completed. Click “ok” and exit the key add pre.

22 (65)

3.Key Add

After the key add pre process, please connect car to do key add and key delete. Put the FEM/BDC modules back into car, then connect Key Master DP with the car OBD. Enter the menu, choose “key add”.

22 (66)

Then, put the key on the emergency starting position and click “ok”. Emergency starting position is on the right side of the steering column shell, a place with key sign as below:

Attach the key to the key sign as below:
22 (68)

Key Master DP will recognize the valid key and show its frequency, click “Yes” to continue.

22 (69)

Then the device will show the car key quantity, position and ID, such as the two programmed keys 00 and 02. Now we can add one key at the position 01, or from 03 to 09. We choose the position 08 here.
22 (70) 22 (72)

Put the key to be programmed on the emergency starting position, click “ok” to continue.

22 (73)

If the new key is recognized, the device will show “programming succeeded”, click “ok” to continue.

22 (74)

After key programming succeeded, the programmed key information will be read automatically. Key 08 is the new added key.

22 (75)

4.Key Delete

The operation for key delete is the same as key add. Enter key enable /disenable, read and remember the key ID. Then go to key add— key delete, choose the key to be deleted according to the prompt(the current key can not be deleted, no worried about deleting it by mistake).

No Comments in Auto Scanner Tools

Know About MAN-cats T200 MAN Diagnostic Tool

MAN Diagnostic Tool MAN Cats T200 is a new arrival device , let’s see what’s the tool is .

17-1

Heavy Duty Diagnostic MAN-cats T200 is an external diagnosis system with the most extensive test depth for electrical systems in MAN commercial vehicles. This Dealer Level diagnosis system is ideally suited to use in a workshop as well as mobile usage

Features:

1. It is special dealer level diagnostic too for MAN trucks.

2. It support both Diagnose and Offline programming.

3. With one year warranty.

4. Support multi-languages: German, English, French, Spanish, Italian, Dutch, Portuguese, Russian, Greek, Croatian, Turkish, Polish, Romanian

5. Software do not support update

Examples of Diagnosable Systems:

•  Electronic brake systems (EBS).
•  Electronically controlled air suspension (ECAS).
•  Engine regulation (EDC).
•  Retarder.
•  Gearbox.
•  Air-conditioning systems.
•  Central computer.
•  Instrumentation.
•  Door module.
•  Airbag.
•  And much more.

Possibilities of Use:

•  Simple testing of actuators.
• Visualisation and assessment of current sensor signals.
•  Identification of control unit in assembled condition.
•  Depiction of all stored diagnosis entries.
•  Fast orientation on vehicle by means of integrated overview wiring diagrams.
•  HD-OBD scantool (Heavy Duty On Board Diagnosis), read-out and presentation of data relevant to exhaust gas.

Package Including:

1pc x T200 Communication Interface
1pc x OBD2 Main Cable
1pc x 12-pin Round Cable
1pc x OBD2 Adapter Cable
1pc x USB Cable
